• Bevel capability (-1 to 48°) with positive stops at 22.5° and 45°
• Close to the wall cutting (11/16 inch) for expanded cutting applications
• Ideal for cutting large wood panels and other wood materials in confined areas
• 1-1/2 inch OD dust port directs material away from the operator and connects to a vacuum system
• Electronic speed control maintains constant speed under load for smooth cutting
• Built-in current limiter helps prevent motor burnout
• Soft start feature for smooth start-ups
• Easy-to-set depth adjustment with large scale
• Smooth and convenient plunge release lever for operator comfort
• Magnesium components deliver a well balanced and lightWeight saw at only 9.7 lbs.
• Dual front and rear bevel supports provide additional rigidity for precise and accurate bevel cuts
• Precise bevel cutting as the position of the blade enters the material on the same cutting line whether cutting straight or bevel
• Locking lever holds the blade in position so that the wrench can be inserted through the hole in the blade case for easier blade installation
• Blade wrench attaches to the saw for fast and convenient blade changes
• Built-in depth stop allows a preliminary cut of 1/16 inch to be performed before the entire material is cut through for clean and splinter-free cutting
• Rubberized handles for added comfort
• Large 1-7/16 inch rear dust port directs material away from the operator and easily connects to a vacuum system



Specifications



• Blade Diameter 6-1/2"
• Arbor (mm) 20 mm
• Max. Cutting Capacity (at 90°) 2-3/16"
• Max. Cutting Capacity (at 45°) 1-9/16"
• No Load Speed (variable Speed) 2,000 - 5,200 RPM
• Watts Out 1,800
• AMPS 12
• Overall Length 13-3/8"
• Net Weight 9.7 lbs.
• Shipping Weight 16.9 lbs
